MC-002
電動分光器
電動分光器
| Specification | |
| Feature | Value |
| Design | Czerny-Turner, dual-grating turrets |
| Focal Length | 110mm |
| Beam Path | Straight through standard, right angle provided on request. |
| Wavelength Drive | Worm and wheel with microprocessor control and anti-backlash gearing. Bi-directional. Usable in positive or negative grating orders. |
| Wavelength Precision | 0.2nm |
| Wavelength Accuracy | ± 0.6nm |
| Slewing Speed | >100nm/second |
| Stray Light | <10-5 |
| Slits | Standard Set includes; 0.125mm, 0.15mm, 0.30mm, 0.6mm, 1.2mm and 2.4mm x 4.0mm. For other sizes, consult SP. |
| Max Resolution | <1nm w/1200G/mm grating and standard slits |
| Gratings | One to two gratings. (30 x 30mm) must be purchased. See CM grating options page |
| Software | Demonstration control program and LabView driver included. |
| Power | UL listed 110/220V power pack |
| Interface | RS232 standard |
| Options |
|
